125CC,Air cooled, 4-stroke, Single Cylinder
Start Kick
Manual 4 speed transmission
Fuel Tank Capacity 1.2 US gallons
Front Hand Brake Hydraulic Disc
Rear Foot Brake Hydraulic Disc
Tire Front 70/100 - 17
Tire Rear 90/100 - 14
Seat Height 35 Inches
Handlebar height 45 inches
Ground Clearance 14.5 Inches
Wheelbase 50 Inches
Vehicle Assembled 162 LBS
LxWxH 72x30x46 Inches
Engine Type140cc, Air Cooled, 4-Stroke, Single Cylinder
Start Type Kick
Manual 4 speed transmission
Fuel Tank Capacity 1.2 US gallons
Front Hand Brake Hydraulic Disk
Rear Foot Brake Hydraulic Disc
Tire Front 70/100-17
Tire Rear 90/100-14
Seat Height 35 Inches
Handlebar height 45Inches
Ground Clearance 14.5
Wheelbase 50 Inches
Vehicle Assembled 163 Lbs
LxWxH 72x30x46 Inches
Turning Radius 1.5m
Maximum Speed 22 mph
Climbing Angle > 12°
Start method Pull start
Transmission Chain Drive
Engine Torque 4.6NM/3000min
Engine 105CC
Power 1.3kw/3600r/min
Automatic Clutch
Fuel Tank Capacity 1.4L
Wheel Models 145 /70-6
Break Methods Rear Disk Breaks
Gross Weight 45kg
Vehicle LxWxH 50 x 27.2 x 32.5 inches
Maximum Speed 22 mph
Climbing Angle ≥1 2 °
Sideslip ≤5m/km
Turning Radius 1.5 m
Load Capacity 198 lb (90 kg)
Engine Capacity 196CC
Start Method Pull Back Push Start
Clutch Automatic
Engine Torque 11 N, M/ 2500 r/min
Engine Oil Grade SF 15W-40
Engine Oil Capacity 0.6l
Power 4.0 kw/ 3600 r/min
Fuel Tank Capacity 4. L
Wheel Model 19x7-8
Gross Weight 192 lb
Vehicle LxWxH 63.5 x 29.5 x 36
